Foshan Shunkangda Medical Tech Co.,Ltd
Product features：
Material: aluminum alloy
Function: aluminum alloy frame, surface spray treatment, detachable armrest, adjustable width and height, wide Pu armrest pad; Detachable foot rest, plastic pedal with high section height, reversible, car seat, adjustable backrest angle, foldable, a storage rack is designed behind the seat, which can hold salutes below 10kg, and anti falling device is equipped.
Product parameters：
Total width (CM) :66
Folding height (CM): 69
Seat width (CM): 46
Rear wheel specification (CM) :30
Front wheel specification (CM) :20
Seat height above the ground (CM) :51
Seat depth (CM) :42.5
Total length (CM) :107
Total height (CM): 115
Backrest height (CM) :71
Handrail height (CM): 21-24.5
Distance between handrails (CM): 48
Foot rest height from the ground (CM) :7
Maximum user mass (kg): 110
Weight (kg): 61
Wheelbase (CM): 52.5
Track width (CM) :64.5
Turning radius (CM) :90
Tire pressure (kPa): 200
Motor model :DG-168/A2
Rated voltage of motor (V): 24V
Motor rated power (W) :200W
Battery model :6-DM-28
Rated capacity of battery (A.H): 28
Rated voltage of battery (V): 12
Quantity of battery equipment (PCs.) :2
Charger power supply :115-230v
Charger output voltage (V) :24V
Maximum output current of charger (a) :5
Maximum output current of governor (a) :≤50
Continuous operating current of governor (a) :≤5
Maximum speed (km/h): ≤6
Braking performance (m) :1.2
Climbing capacity (°) :12
Power consumption (kw.h/100km) :Not more than 4.5 kw 15% of h/100 km
Longitudinal stability (°) :20 (static)
Lateral stability (°) :15 (static)
pc/ctn： 1
Certificate：ISO13485/ ISO9001/ TUV/FDA/ CE
